Products
Construction : Gear Drive
Weight : 2.4 Kg
Noise Grade : ≤50 dB
Rated Voltage : 36V/48V DC
Rated Power : 250 W
Max Torque : 40 Nm
reliable and compact design
| Construction | Gear Drive |
| Weight (Kg) | 2.4 |
| Color | Black / Silver |
| Noise Grade (dB) | ≤50 |
| Mounting Parameters | |
| Brake Type | Disc Brake / V Brake |
| Cable Routing | Shaft side, Left |
| Spoke specification | 36H*13G |
| Free wheel | Screw-on 7S |
| Rated Voltage (DC) | 36V/48V |
| Rated Power (W) | 250 |
| Max Torque (Nm) | 40 |
| Max efficiency | ≥80% |
| Operation |
| Certifications | |
| Waterproof | IPX5 |
| Cable Length (mm) | 250 |
| A: 42mm |
| B: 121mm |
| C: 109mm |
| D: M12x1mm |
| E: 15.3mm |
| F: 38mm |
| G: mm |
| O.L.D: 137 |
| O.L.D |
| Construction |
| Rated Voltage (DC) |
| Rated Power (W) |
| Max Torque (Nm) |
| Max efficiency |
| Weight (Kg) |
| Color |
| Noise Grade (dB) |
| Operation |
| Mounting Parameters |
| Brake Type |
| Cable Routing |
| Cable Length (mm) |
| Spoke specification |
| Free wheel |
| Certifications |
| Waterproof |
M129SD
eCity
| 137 |
| Gear Drive |
| 36V/48V |
| 250 |
| 40 |
| ≥80% |
| 2.4 |
| Black / Silver |
| ≤50 |
| Disc Brake / V Brake |
| Shaft side, Left |
| 250 |
| 36H*13G |
| Screw-on 7S |
| IPX5 |
M108VD
eCity
| 100 |
| Gear Drive |
| 36V |
| 250 |
| 30 |
| ≥80% |
| 2 |
| Grey / Sliver |
| ≤50 |
| Disc Brake / V Brake |
| Through shaft,Left |
| 250 |
| 36H*13G |
| / |
| IPX5 |
